Product Code: Technical0034
Rotary Air Compressor Test Rig
The Apparatus consists of a rotary vane compressor driven by an electric
motor; Air intake is measured by an orifice meter and manometer, Discharge
"pressure is measured by a pressure gauge. Power input of the compressor
measured by an Energymeter. Thus the students can determine volumetric
efficiency, power consumption and free air discharge of compressor.
SPECIFICATIONS:
Vane compressor - Rotary compressor, driven by 3 HP motor.
Calibrated orifice meter with water manometer to measure air intake.
Energy meter to measure input of the meter.
Pressure gauge to measure discharge pressure.
Control valve at delivery side.
Stop clock.
A technical manual accompanies the unit.
SERVICES REQUIRED:
Floor space of approx. 1.5 X 1.5 m. X 1.5 M. height.
440V, 16A, 3ph. supply.
Tachometer.
